Zástrčkový konektor na kabel Weidmüller SCZ 3.81/05/180FIZE SN OR BX 1237560000, pólů 5, rozteč 3.81 mm, 50 ks

The inverted SCZ pin plug with clamping-yoke screw connection is designed for straight wire outlet connections. It can be used in two ways: for wire-to-wire connections together with the BCZ As a mating plug for the touch-safe BCL-SMT socket block on the PCB. The SCZ is available in four different versions: Without flange ("G", closed) With standard flange ("F", with nut) for wire-to-wire connectionsWith inverted flange ("FI", with screw) for screw connection to the BCL-SMT LFIWith Weidmüller's patented release latch (LR) for lock-and-release latching with the BCL-SMT LFI: no strain and no tools needed. Weidmüller's 3.81-mm-pitch (0.15 inch) plug-in connectors are compatible with the layouts of standard connectors and offer space for labelling and coding. 0.20 - 1.5 mm² (IEC) / 28 - 16 AWG (UL) 250 V (IEC) / 300 V (UL) 17.5 A (IEC) / 10 A (UL) Obsahuje: 50 ks·Počet řádků: 1·Počet pólů: 5
